StarTech.com HDMI Video Over IP Gigabit LAN Ethernet Extender Kit - 1080p - 1 Output Device - 330 ft Range - 2 x Network (RJ-45) - 4 x USB - 1 x HDMI Out - WUXGA - 1920 x 1200 - Twisted Pair - Category 6 - Rack-mountable, Desktop - TAA Compliant
Description
The HDMI over IP kit lets you extend an HDMI signal over your network. You can use additional receivers (sold separately) to distribute the HDMI signal to multiple locations and combine your remote displays to create a video wall.
Versatile configuration options
In a point-to-multipoint setup, the HDMI over IP kit can be connected through an unmanaged or managed Gigabit LAN portal. You can connect one or multiple sources (transmitters) to multiple displays (receivers) over IP, using a managed Gigabit Ethernet switch (with IGMP). For additional scalability, you can combine up to 16 different kits.
For smaller-scale applications, the extender kit can be used as a point-to-point video extender. You can connect the transmitter and receiver units directly over Cat5 or Cat6 cabling for a small-scale, one-to-one HDMI extension up to 330 feet (100 meters).
Manage your video distribution from your mobile device
The HDMI distribution kit features easy-to-use video control software that helps you manage your IP video distribution. The app is simple to set up with automatic hardware detection, and lets you switch video sources for each remote display. You can also intuitively create and manage a video wall for an impressive digital signage presentation to catch the attention of your audience.
The software is available on iOS for your iPhone or iPad, and Android for your smartphone or tablet.
Professional, cost-effective, simple installation
The HDMI over IP extender kit includes optional mounting hardware for a tidy installation. Ideal for high-definition applications, the extender supports 1080p video resolutions and digital stereo audio. Plus, because the extender uses standard non-proprietary Cat5e or Cat6 Ethernet cable with RJ45 connectors, it eliminates both the expense and hassle of running specialized cables.The extender also features an EDID copy function, which ensures native resolution and maximum compatibility with your display or projector for a convenient plug-and-play installation.
NOTE: Your router must support IGMP snooping. Please refer to your network switch or router documentation to ensure IGMP snooping is supported and enabled.
The ST12MHDLAN is TAA compliant and backed by a StarTech.com 2-year warranty with free lifetime technical support.
Specifications
45111815
4.35lb
3.5in
10in
11.9in
StarTech.com
StarTech.com
Range Extenders
Black
Wired
Restriction of Hazardous Substances (RoHS)
Yes
Rack-mountable
WUXGA
Yes
2 Year
StarTech.com
ST12MHDLAN
http://www.startech.com
330 ft
1920 x 1200
Twisted Pair
Yes
1
2
1
4
- 1 x HDMI over IP receiver
- 1 x foot pad set
- 1 x universal power adapter (NA / EU / UK / AU)
- 1 x mounting bracket
- 1 x instruction manual
1
Black
HDMI Video Over IP Gigabit LAN Ethernet Extender Kit - 1080p
Video Extender Transmitter/Receiver
5.10"
1.10"
2.07 lb
3.80"
Yes
5.10"
1.10"
2.07 lb
3.80"
Category 6
Yes
